Description

Scope of Delivery:
- 1x Festool OF 1400 router
- 1x chip catcher KSF-OF 1400
- 1x collet SZ-D 8.0/OF 1400/2000/2200
- 1x collet SZ-D 12.0/OF 1400/2000/2200
- 1x side stop SA-OF 1400
- 1x KR-D 30.0/OF 1400 copying ring
- 1x top extraction bonnet
- 1x open-end spanner SW 24
- 1x Systainer SYS3 M 337

Product Description:
The OF 1400 from Festool is a solid router that is suitable for various tasks thanks to its relatively low weight. The 70 mm routing stroke is impressive when countersinking fittings or routing with routing templates. The torsion-resistant base plate with guide pillars clamped on both sides ensures stable support when working. Thanks to the convenient spindle stop with rocker and ratchet principle, the router bit can be changed in a flash without having to move the spanner. The routing depth can be set easily and precisely to an accuracy of 1/10 mm. The quick brake stops the milling cutter in a matter of seconds, ensuring a high level of safety when milling. The MMC Electronic ( Multi-Material-Control Electronic ) guarantees material-compatible working. Changing the copy ring is very easy due to the elimination of the mounting tool. Thanks to the chip catcher and the extraction bonnet, dust and chips can be easily extracted when routing edges. It also has a comprehensive range of equipment that can be used to master almost all routing tasks such as rounding, chamfering, rebating and profiling edges, routing circles and cut-outs, grooving back panels and countersinking burr mouldings. Festool is a premium manufacturer of power tools that is characterised above all by its long tradition and very high quality of workmanship.

Technical Data:
- Manufacturer: Festool
- Manufacturer's designation: OF 1400 EBQ-Plus
- Manufacturer number: 576207
- Power consumption: 1400 W
- Idle speed: 10 000 - 22 500 min-¹
- Collet Ø: 6 - 12.7 mm
- Milling stroke: 70.00 mm
- Milling depth fine adjustment: 8.00 mm
- Table opening: 63.00 mm
- Dust extraction connection Ø: 27/36 mm
- Product weight: 4.40 kg
- Drive type: Mains
- Uncertainty (vibration) K: 2.00 m/s²
- Uncertainty (noise) K: 3.00 dB
- Total vibration mean value ah: 3.50 m/s²
- Series of standards EN: 60745-2-17
- A-weighted sound pressure level Lp: 82.00 dB(A)
- A-weighted sound power level Lw: 93.00 dB(A)
- For commercial use, please observe the building regulations!

For commercial use, please observe the building regulations!

Specifications

• Hersteller: Festool
• Gewicht: 4400 g
• Antrieb: Netzbetrieb
• K-Wert Vibration: 2 m/s²
• Länge: 296 mm
• Breite: 215 mm
• Höhe: 398 mm
• Leistung: 1400 W
• Max. Leerlaufdrehzahl: 22500 U/min
• Schalldruckpegel: 95 dB
• Max. Vibration: 3.5 m/s²
• K-Wert Geräusch: 3 dB
• Schallleistungspegel: 106 dB
• Kabellänge: 4 m
• Max. Fräser-Ø: 45 mm
• Max. Spannzangen-Ø: 12.7 mm
• Anschluss Staubabsaugung-Ø: 27/36 mm
• Max. Fräsbreite: 0 - 35 mm
• Frästiefen-Feineinstellung: 8 mm
• Fräshub: 70 mm
• Tischöffnung: 63 mm
