Description

Scope of Delivery:
- 1x Festool TDC 18/4 cordless drill driver
- 1x Festool PZ 2 bit
- 1x Festool CENTROTEC magnetic bit holder BH 60 CE-Imp
- 1x Festool CENTROTEC tool chuck
- 1x Festool FastFix quick-action drill chuck 13 mm KC 13-1/2-MMFP
- 1x Festool additional handle
- 1x Festool SYS3 M 187 Systainer

Product Description:
With the TDC 18/4, Festool offers a powerful cordless drill driver for the highest demands. The combination of a handy design and enormous power enables comfortable and effective working. Thanks to the 4 different gears, the drill driver can be optimised for all applications. This means that screwing with 50 Nm is just as possible in 1st gear as drilling in 4th gear at 3600 rpm. The brushless EC-TEC motor combines enormous resilience and endurance with low wear and therefore a long service life. Thanks to the FastFix interface, the attachments can be changed quickly and without tools. The KickbackStop function minimises the risk of serious injury when the drill driver jams by stopping the motor, thereby protecting the user's health. Festool is a premium manufacturer of power tools that is characterised above all by its long tradition and very high quality workmanship.

Technical Data:
- Manufacturer: Festool
- Manufacturer's designation: TDC 18/4
- Manufacturer number: 575601
- Battery voltage: 18 V
- Gears: 4
- Idle speed 1st/2nd gear: 0 - 500/0 - 800 min-¹
- Idle speed 3rd/4th gear: 0 - 2350/0 - 3600 min-¹
- Drilling diameter wood/steel: 70/13 mm
- Torque setting 1st/2nd gear: 2 - 20/2 - 20 Nm
- Max. Torque wood/steel: 50/75 Nm
- Drill chuck clamping width: 1.5 - 13 mm
- Battery capacity: 4.0/5.2 Ah
- Product weight with battery: 1.9/2.0 kg
- Drive type: Battery
- Drilling in metal: Total average vibration value ah: 3.00 m/s²
- Drilling in metal: Standards series EN: 62841
- Drilling in metal: Uncertainty (noise) K: 5.00 dB
- Drilling in metal: Uncertainty (vibration) K: 1.50 m/s²
- Drilling in metal: A-weighted sound pressure level Lp: 73.00 dB(A)
- Drilling in metal: A-weighted sound power level Lw: 84.00 dB(A)
- Screws: Total average vibration value ah: 2.50 m/s²
- Screws: Standards series EN: 62841
- Screws: Uncertainty (noise) K: 5.00 dB
- Screws: Uncertainty (vibration) K: 1.50 m/s²
- Screws: A-weighted sound pressure level Lp: 73.00 dB(A)
- Screws: A-weighted sound power level Lw: 84.00 dB(A)
- For commercial use, please observe the building regulations!

For commercial use, please observe the building regulations!

Specifications

• Hersteller: Festool
• Gewicht: 1900 g
• Antrieb: Akku
• Spannung: 18 V
• K-Wert Vibration: 1.5 m/s²
• Länge: 396 mm
• Breite: 296 mm
• Höhe: 337 mm
• Max. Leerlaufdrehzahl: 3600 U/min
• Schalldruckpegel: 73 dB
• Max. Vibration: 3 m/s²
• K-Wert Geräusch: 5 dB
• Schallleistungspegel: 84 dB
• Max. Drehmoment: 75 Nm
• Bohrleistung in Holz: 70 mm
• Bohrleistung in Stahl: 13 mm
• Schnellspannfutter: Ja
• Getriebe: 4-Gang
• Bohrfutterspannw.: 1.5 - 13.0 mm
• Seitengriff: Ja
